FS6 6-piston aluminum forged model that can be fitted with a Φ380 rotor.
In addition, there is also a more affordable rotor-less kits that can be mounted on genuine rotors.
Total length : 288mm / Total width : 153mm ※ / Total height :74mm
※Excludes the protrusion of the brake line attachment section.
- 削り出し製法
| Materials, production methods | Aluminium alloy/Forged |
| Surface finishing | Hard alumite with powder coating |
| Piston diameter | 30/36/38mm |
| Rotor dimensions | 345/355/380mm ×32mm |
| No. of pads | 2Pads / 1Caliper |
| FRONT | ¥404,800 （¥368,000 Excluding tax）～ |
| FRONT/ Type using genuine rotor |
¥291,500 （¥265,000 Excluding tax） |
※ NS-C pads are included as standard. Other pads are also available.
※When mounting, you must machine the genuine disc back plate.
■CALIPER KIT
Calliper, Calliper Steel Bracket, Brake Pad, 2Piece Rotor(Not included in the genuine rotor kit), Teflon Brake line, Pad Support Spring, All bolts
Product specifications, prices, manufacture and sales are subject to change or termination without notice.
